Features

? Supports PCI Express Card Electromechanical Specification Revision 2.0

? Supports PCI Bus Power Management Interface Specification Revision 1.2

? Supports USB Battery Charging Specification Revision 1.2

? Compliant with Universal Serial Bus 3.0 Specification Revision 1.0, which is released by USB

? Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices

? Supports all USB compliant data transfer types as follows; Control / Bulk / Interrupt / Isochronous transfer

? Supports the following speed data rates as follows:

Low-speed (1.5Mbps) / Full-speed (12Mbps) / High-speed (480Mbps) / Super-speed (5Gbps)

? Compliant with Intel’s eXtensible Host Controller Interface (xHCI) Specification Revision 1.0

? Supports USB debugging capability on all super-speed ports

? Supports USB legacy function.

? Supports ExpressCardTM Standard Release1.0

? Supports 4 downstream ports for all speeds

? Built-in 15-pin power connector for receiving extra power supply from system

? Hot-swapping feature allows you to connect/disconnect devices without powering down the system

? 4 sets of power modules can shield electromagnetic interference to ensure the integrity and stability of data transmission

System Requirement

? Windows ,Linux, MAC OS 10.8 or above
